PIXMA iP4200 SERVICE MANUAL. When changes are made to the contents of the manual, Canon will release technical information when necessary. When substantial changes.
• PIXMA iP5200R SERVICE MANUAL Canon Copyright 2005, Canon U.S.A. This technical publication is the proprietary and confidential information of Canon U.S.A. Which shall be retained for reference purposes by Authorized Service Facilities of Canon U.S.A. Its unauthorized use is prohibited.
• Copyright All rights reserved. No parts of this manual may be reproduced in any form or by any means or translated into another language without the written permission of Canon Inc., except in the case of internal business use. • This manual consists of the following three parts to provide information necessary to service the PIXMA iP5200: Part 1: Maintenance Information on maintenance and troubleshooting of the PIXMA iP5200 Part 2: Technical Reference New technology and technical information such as FAQ's (Frequently Asked Questions) of the PIXMA. CLEANING MODE AND AMOUNT OF INK PURGED 3. PRINT MODE 4. FAQ (Problems Specific to the iP5200 and Corrective Actions) Part 3: APPENDIX 1.
BLOCK DIAGRAM 2. CONNECTOR LOCATION AND PIN LAYOUT 2-1. Logic Board Ass'y 2-2. Carriage Board (Print Head Connector) PIXMA iP5200 Specifications. • Part 1 MAINTENANCE. MAINTENANCE 1-1.
Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by Service Engineer (1) Adjustment Approx. Adjustment Timing Purpose Tool time Destination At logic board replacement To set the destination. Settings Perform in the (EEPROM service mode. Customer Maintenance Approx. Adjustment Timing Purpose Tool time Print head At print head replacement.
To ensure accurate dot - Printer buttons 3 min. Alignment placement. - Computer (automatic settings via the printer driver) Print head When print quality is not To improve nozzle - Printer buttons 1 min. • Windows XP driver, using Photoshop 7.0. Photo chart: When printing the Canon standard pattern on 4' x 6' Photo Paper Plus Glossy in borderless printing, with the default settings in the Windows XP driver, using Windows XP Photo Printing Wizard.
• immediately after it is unsealed, until the ink is out. Hp Rgs Desktop Trial Edition here. Ink yield may vary depending on texts and photos printed, application software, print mode, and type of paper used. Special Tools Name Tool No. Application Remarks Grease FLOIL QY9-0057-000 To be applied to the sliding In common with portions of the carriage shaft and the S500 and.
LIST OF ERROR DISPLAY / INDICATION Errors are indicated by the LED, and warnings are displayed on the monitor of the computer connected to the printer. Gpt Website Php Script Rar Extractor. Operator Call Errors (by Alarm LED Blinking in Orange) Alarm Error [Error code] Solution Remarks blinking. • [1401] Print head temperature sensor error [1403] Faulty EEPROM data of the print head [1405] Close the inner cover, and press the 6 times Inner cover open. [1841] Resume/Cancel button.
Inner cover open during Close the inner cover, and press the Resume/Cancel button to clear the printing on paper. • button to eject the paper being used at paper at error error occurrence. Printing will resume occurrence is from on the front side of the next page. Skipped (not printed).
11 times Failed in automatic print head Press the Resume/Cancel button. The error is alignment.
Service Repair Manuals of Canon Pixma Ip 3680 Printer is a handbook published by Canon manufacturer or a specialized publishing company that contains instructions and specifications for the maintenance, repair, and how to fix all error of a specific Canon Pixma Ip 3680 Printer. It may include Exploded Views, Parts List, System Diagram, Disassembly and Reassembly, Alignment, Troubleshooting guides. Service Repair Manuals of Canon Pixma Ip 3680 Printer is often used for the Service Center of Canon. Compatible Models: Canon Pixma Ip 3640, Canon Pixma Ip 3680, Canon Pixma Ip 4260, Canon Pixma Ip 4860, Canon Pixma Ip 5480. How-to-fix-errors-Canon Pixma Ip 3680 Error messages in Service Repair Manual Canon Pixma Ip 3680: LED (Blinking in orange) – 2 times with error code: [1000], [1003]. – 3 times with error code: [1300], [1303], [1250].
